Yamaha TMAX 560 (2020–2025)
Fluid capacities, consumables, drivetrain, tire pressure & wear limits
The Yamaha TMAX 560 (2020–2025) takes 2.9 L of oil with a filter change (2.6 L without).
Fluid Capacities
Oil capacity (with filter)2.9 L"With oil filter removal" quantity in the manual.
Oil capacity (without filter)2.6 L"Oil change" quantity (no filter change) in the manual.
Oil capacity (dry fill)3.5 L
Coolant (radiator)1.5 LMY2022+ value. MY2020-2021 was 1.54 L (radiator, including all routes).
Consumables
Engine oil grade10W-40, API service SG or higher, JASO standard MA
Coolant typeYAMALUBE coolant (ready-to-use, pre-diluted); if unavailable, ethylene glycol antifreeze with corrosion inhibitors for aluminum engines, mixed 1:1 with distilled waterWeb-confirmed — Yamalube coolant is Yamaha's own listed part for the TMAX line, with ethylene glycol as the documented fallback.
Spark plug (OEM)NGK LMAR7G
Oil filter (OEM)5GH-13440-80Same filter part number as the CP2/CP3 twin/triple lineup and the R1 — not independently confirmed against this bike's own service manual
Drivetrain
Drive belt width31.4 mmV-belt width service limit — the manual does not separately publish a nominal (new) width. Replace when worn to this limit, or on the dash V-belt replacement indicator (every 20,000 km / 12,000 mi).
Brakes & Tires
Front tire size120/70R15M/C 56H
Rear tire size160/60R15M/C 67H
Front tire pressure225 kPaSolo rider. Unchanged for 2-up riding.
Rear tire pressure250 kPaSolo rider. 280 kPa (41 psi) for 2-up riding.
Brake fluid typeDOT 4
Wear Limits
Front brake disc (min)3.5 mm
Rear brake disc (min)4.5 mm
Brake pad — front (min)0.5 mm
Brake pad — rear (min)0.8 mm
Clutch friction plate (min)2.82 mmWet centrifugal clutch inside the CVT — not rider-operated, but still a serviceable wear item.
Drive belt (wear limit)31.4 mm
