Suzuki GSX-R750 (2006–2007)
Fluid capacities, consumables, drivetrain, tire pressure & wear limits
The Suzuki GSX-R750 (2006–2007) takes 2.5 L of oil with a filter change (2.2 L without).
Fluid Capacities
Oil capacity (with filter)2.5 L
Oil capacity (without filter)2.2 L
Oil capacity (dry fill)2.9 LSuzuki calls this 'overhaul' capacity
Coolant (radiator)2.4 LEngine side, excluding reservoir. Reservoir tank adds another 0.25 L (total solution capacity ≈2.7 L).
Consumables
Engine oil grade10W-40, API SF/SG or SH/SJ, JASO MA
Coolant typeAntifreeze/engine coolant compatible with aluminum radiator, mixed with distilled water only, 50/50 ratio (do not exceed 60% mix)
Oil filter (OEM)Not located in extracted manual sections
Air filter (OEM)Not located in extracted manual sections
Spark plug (OEM)NGK CR9E or DENSO U27ESR-N
Front brake pads (OEM)Wear checked against a grooved limit line machined into the pad — no OEM part number located
Rear brake pads (OEM)Wear checked against a grooved limit line machined into the pad — no OEM part number located
Drive chainRK525ROZ5Y, 116 Links
Clutch free play10–15 mm
Drivetrain
Chain size525
Chain links116
Chain slack20–30 mmOn side-stand
Front sprocket (OEM)17 TDerived from final reduction ratio 2.647 (45/17)
Rear sprocket (OEM)45 T
Brakes & Tires
Front tire size120/70 ZR17 M/C (58W)
Rear tire size180/55 ZR17 M/C (73W)
Front tire pressure250 kPa
Rear tire pressure290 kPa
Brake fluid typeDOT 4
Wear Limits
Front brake disc (min)5 mm
Rear brake disc (min)4.5 mm
Clutch friction plate (min)2.42 mmDrive plate thickness service limit
